Sonicwall Network Security Virtual 200
harga hubungi kami!!!
Deskripsi
| Operating system | SonicOS1 | ||||
| Supported Hypervisors | VMware ESXi v5.5 / v6.0 / v6.5 / v6.7, Microsoft Hyper-V | ||||
| Supported Public Cloud Platforms (Instance Type) | AWS (c5.large), Azure (Std D2 v2) | N/A | AWS (c5.xlarge), Azure (Std D3 v2) | AWS (c5.2xlarge), Azure (Std D4 v2) | AWS (c5.4xlarge), Azure (Std D5 v2) |
| Licensing | BYOL, PAYG2 | ||||
| Max Supported vCPUs | 2 | 3 | 4 | 8 | 16 |
| Interface Count (ESXi/ Hyper-V/ AWS/ Azure) | 8/8/2/2 | 8/8/-/- | 8/8/4/4 | 8/8/8/8 | 8/8/8 |
| Max Mgmt/DataPlane Cores | 1/1 | 1/2 | 1/3 | 1/7 | 1/15 |
| Min Memory3 | 6 GB | 6 GB | 8 GB | 10 GB | 12 GB |
| Max Memory4 | 6 GB | 8 GB | 10 GB | 14 GB | 18 GB |
| Supported IP/Nodes | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited |
| Minimum Storage | 60 GB | ||||
| SSO users | 500 | 5,000 | 10,000 | 15,000 | 20,000 |
| Logging | Analyzer, Local Log, Syslog | ||||
| High availability | Active/Passive5 | ||||
| FIREWALL/VPN PERFORMANCE6 | NSv 200 | NSv 300 | NSv 400 | NSv 800 | NSv 1600 |
|---|---|---|---|---|---|
| Firewall Inspection Throughput | 4.1 Gbps | 5.9 Gbps | 7.8 Gbps | 13.9 Gbps | 17.2 GBPS |
| Full DPI Throughput (GAV/GAS/IPS) | 900 Mbps | 1.6 Gbps | 2.2 Gbps | 4.0 Gbps | 6.4 Gbps |
| Application Inspection Throughput | 2.3 Gbps | 3.4 Gbps | 4.1 Gbps | 5.5 Gbps | 6.4 Gbps |
| IPS Throughput | 2.3 Gbps | 3.4 Gbps | 4.1 Gbps | 5.5 Gbps | 6.7 GBPS |
| Anti-Malware Inspection Throughput | 900 Mbps | 1.6 Gbps | 2.2 Gbps | 4.0 Gbps | 6.6 Gbps |
| IMIX Throughput | 1.5 Gbps | 2.3 Gbps | 2.8 Gbps | 4.2 Gbps | 5.3 Gbps |
| TLS/SSL DPI Throughput | 1.1 Gbps | 1.2 Gbps | 1.8 Gbps | 3.4 Gbps | 5.1 GBPS |
| VPN Throughput | 750 Mbps | 1.4 Gbps | 1.9 Gbps | 4.2 Gbps | 8.4 Gbps |
| Connections per second | 13,760 | 24,360 | 37,270 | 75,640 | 125,000 |
| Maximum connections (SPI) | 225,000 | 1M | 1.5M | 3M | 4M |
| Maximum connections (DPI) | 125,000 | 500,000 | 1.5M | 2M | 2.5M |
| TLS/SSL DPI Connections | 8,000 | 12,000 | 20,000 | 30,000 | 50,000 |
| VPN | NSv 200 | NSv 300 | NSv 400 | NSv 800 | NSv 1600 |
| Site-to-Site VPN Tunnels | 75 | 100 | 6000 | 10,000 | 25,000 |
| IPSec VPN clients (Maximum) | 50(1000) | 50(1000) | 2000(4000) | 2000(6000) | 2000(10,000) |
| SSL VPN NetExtender Clients (Maximum) | 2(100) | 2(100) | 2(100) | 2(100) | 2(100) |
| Encryption/authentication | DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B, Common Access Card (CAC) | ||||
| Key exchange | Diffie Hellman Groups 1, 2, 5, 14v | ||||
| Route-based VPN | RIP, OSPF, BGP | ||||
| NETWORKING | NSv 200 | NSv 300 | NSv 400 | NSv 800 | NSv 1600 |
| IP address assignment | Static, DHCP, internal DHCP server, DHCP relay | ||||
| NAT modes | 1:1, many:1, 1:many, flexible NAT (overlapping IPs), PAT | ||||
| Max VLAN7 | 128 | 128 | 128 | 128 | 128 |
| Routing protocols | BGP, OSPF, RIPv1/v2, static routes, policy-based routing | ||||
| QoS | Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p | ||||
| Authentication | XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix | ||||
| VoIP | SIP | ||||
| Standards | TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, L2TP, PPTP, RADIUS | ||||
| Max SD-WAN groups | 38 | 38 | 70 | 102 | 102 |
| Max SD-WAN members per product | 76 | 76 | 140 | 204 | 204 |
